PE PP Pelletizing/Granulating Line

Name: PE PP Pelletizing/Granulating Line
Brand: Zhang Jia Gang QING CHEN YU Machinery Co., Ltd.

The PE PP Pelletizing/Granulating Line is a state-of-the-art processing line that transforms polymer material into tiny pellets or granules of consistent size and shape. This technological advancement is crucial for plastic recycling and the production of additional plastic materials. The process comprises chilling the extruded melt before cutting the molten polymer into pellets that are then uniformly sized granulated.

Get a Quote 

Products

Applications of PE PP Pelletizing/Granulating Line

Applicable plastic materials: PE, HDPE, LDPE,PP, etc.
Material shapes: rigid flakes, agglomerated film.
Note: depending on different material properties, various downstream equipments are needed.

Technical Specification of PE PP Pelletizing/Granulating Line

Side force feeding type pelletizing line

Model	Screw Diameter(mm)	Main Motor Power(kw)	Side Force Feeder Motor Power(kw)	Capacity(kg/h)
SJ00/30	Φ100	55-75	5.5	150-200
SJ120/30	Φ120	75-90	7.5-11	200-350
SJ130/30	Φ130	90-110	11	300-400
SJ150/30	Φ150	132-160	15	350-500
SJ160/33	Φ160	160-185	15	450-550
SJ180/33-36	Φ180	185-200	18.5	600-800
SJ200/33-36	Φ200	200-250	22	800-1000

Vertical type force feeding pelletizing line

Model	SJ45	SJ65	SJ90	SJ100/120		SJ120/150		SJ150/180		SJ180/200
Model	SJ45	SJ65	SJ90	SJ100	SJ120	SJ120	SJ150	SJ150	SJ180	SJ180	SJ200
Screw Diameter(mm)	Φ45	Φ65	Φ90	Φ100	Φ120	Φ120	Φ150	Φ150	Φ180	Φ180	Φ200
Motor Power(kw)	15	22	37	45-75	37	75-110	45	132-160	55	160-185	75
L/D	25	25-28	25-28	25-33	10-12	28-33	10-12	28-33	10-12	28-36	10-12
Capacity(kg/h)	10-30	50-100	80-150	100-250		150-350		250-500		400-700

*Remarks:

Double stage is optional.
The above capacity is based on film scrap/rigid flake/agglomerated material, actual capacity varies with different condition of raw material.

Working Principle of a PE PP Pelletizing/Granulating Line

PE PP Pelletizing/Granulating Line is a sophisticated equipment that utilizes advanced technology to transform polymer materials into small, uniform pellets or granules. The equipment has several components, including an extruder, cooling system, cutting and pelletizing unit, conveyor system, and control panel. The extruder melts the polymer and extrudes it through a die head to form plastic strands. The plastic strands then pass through a cooling system, which solidifies and cools them to a desired temperature. The cooling process is followed by cutting the strands into pellets of uniform size, which are then fed into the granulator for shaping and finishing. The finished pellets then pass through a conveying system that delivers them to storage containers or packaging equipment.

Why Choose Our PE PP Pelletizing/Granulating Line

To ensure high-grade pellets from a PE PP Pelletizing/Granulating Line, quality control strategies must be in place. First, the raw materials used must be carefully selected and tested to ensure they meet the desired specifications. Secondly, the process parameters such as temperature, pressure, and cooling flow should be monitored and adjusted accordingly to ensure consistent and uniform quality. Additionally, regular equipment maintenance and calibration are essential to prevent equipment failure and ensure consistent product quality. Lastly, the pellets should be subjected to tests such as size distribution, bulk density, and moisture content, and other relevant quality tests to ensure they meet the desired standards. By implementing these control strategies, high-quality pellets can be produced from the PE PP Pelletizing/Granulating Line.

Video of PE PP Pelletizing/Granulating Line

FAQs Of PE PP Pelletizing/Granulating Line

Can a PE PP Pelletizing/Granulating Line handle different pellet sizes and shapes?

Yes, a PE PP Pelletizing/Granulating Line can produce different pellet sizes and shapes by adjusting the cutting and pelletizing unit.
How long does it take to produce pellets using a PE PP Pelletizing/Granulating Line?

The production time for pellets using a PE PP Pelletizing/Granulating Line depends on several factors, including the equipment capacity, material type, and process parameters. However, the process typically takes a few hours.
Can a PE PP Pelletizing/Granulating Line produce pellets with additives?

Yes, a PE PP Pelletizing/Granulating Line can produce pellets with additives such as colorants, flame retardants, and stabilizers.
What is the lifespan of a PE PP Pelletizing/Granulating Line?

The lifespan of a PE PP Pelletizing/Granulating Line depends on several factors, including the quality of the equipment, frequency of use, and maintenance practices. However, a well-maintained and high-quality machine can last for several years.
